| Connector contact | Copper alloy |
| Insulation Material | High performance engineering plastics |
| Operating Temperature | -45℃ to +100℃ |
| Butt connection | Thread |
| Connection mode | Screw |
Size Chart of This Design
| Pin Layout | | |
| Contact diameter | | |
| Rated voltage | | |
Product Paramenters
| Series | L20 connector | Insulation resistance | ≥100MΩ |
| Ambient temperature | -40℃~+105℃ | Contact resistance | ≤10mΩ |
| Voltage resistance | 220V | Mating endurance | ≥3000 |
| Connector contact | gold-plated brass | IP rating | IP67 |
| Shell material | PVC/PA66 | Mating endurance | ≥500 |
| Seal/O-ring | Rubber | Overmold material | PVC/PUR |
Advantage of Our Connector
- Special shape - L shape connector
- 1 way waterproof connector , connect with male / female connector per customer ' s requirement
- High current and voltage
- Connect with cable by soldering , can fix the cable well
- Length of cable - per customer 's requirement
Q/A:
1.Q: Are you a manufacturer?
A: We are manufacture, we can provide one-stop station service for connectors and cables with factory price.
2. Q: Can you produce customized product orders? OEM or ODM orders?
A: Sure. With 10+ years of OEM and ODM manufacturing experience, we are able to provide you with one-stop Custom Connector Solutions.
3. Q: Can you assured the quality?
A: Yes, we’ve have strict QC team, all products will be tested before delivery.
4. Q: What’s the terms of payment?
A: We can accept T/T, LC, Paypal and Western Union.
5. Q: How about your delivery time?
A: Generally, it will take 5 to 10 working days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
6.Q: : After-sales service
A: All the inquiry will be response within 24 hours, the commucation will be effective.
